Description
Features & Benefits
● High efficacy of more than 170lm/W
● Variety of beam patterns for different application.
● Optimal glare control.
● Seamless connection and no light leakage.
● Standalone type and continuous row optional.
● Compact design and streamlined appearance.
● Can be flexibly connected to myriad of shapes.
● Modular design and easy installation
● Variety of beam patterns for different application.
● Optimal glare control.
● Seamless connection and no light leakage.
● Standalone type and continuous row optional.
● Compact design and streamlined appearance.
● Can be flexibly connected to myriad of shapes.
● Modular design and easy installation
Applications
- ● Supermarket
● Warehouse
● Workshop
Specifications
Optical
- Lumen:
4500lm/6500lm/8000lm@1200mm
5500lm/ 8000lm/10500lm@1500mm
10500lm/ 16000lm/ 21000lm@3000mm
CCT: 3000K, 4000K, 5000K
CRI: >80Ra, >90Ra
UGR: <19 (general lighting)
SDCM: ≤3
Beam Angle: 25º, 60º, 90º, double asymmetric, asymmetric
Electrical
- Wattage:
27W/ 40W/ 50W@1200mm
33W/ 50W/ 65W@1500mm
65W/ 100W/ 130W@3000mm
Efficacy: 170lm/W
Voltage: 200-240V
THD: <15%
General
- Size: 1500mm, 3000mm(Length)
Color: White, silver
Finish: Powder coated, anodized
Material: Profile: Extruded aluminum
Cover: PMMA
End Cap: Aluminum alloy
Durability
- Lifespan: 60000h (L90, Tc=55 ºC)
Warranty: 8 years
Operating:-35~45 ºC
IP Protection: IP20
IK Protection: IK05
